Mipro Wireless Microphones Product range
Important changes are happening to wireless audio transmitters including wireless microphones which will take effect from 1 January 2015. This fact sheet provides everything you need to know about the changes and what you can do to prepare.
Wireless Fact Sheet

Download our
Audio Visual newsletter here

Mipro
                                                          Wireless
                                                          Microphones

Click here to
                                    download a printable PDF file Click here to download a printable PDF brochure for the ACT 3 Series
Click
                                      here to download a printable PDF
                                      file Click here to download a printable PDF brochure for the ACT 7 Series


ACT 3 Series
ACT-311

ACT-311

Single-Channel. 1/2U rack-mountable metal receiver.
961 selectable frequencies. 8 preset compatible systems.
Diversity Reception
MORE


ACT-312

Dual-Channel. 1/2U rack-mountable metal receiver.
961 selectable frequencies. 8 preset compatible systems.
Diversity Reception.
MORE
NEW

ACT-30H

Sturdy ABS housing. LCD screen. ACT sync. 24MHz band.
MORE
NEW

ACT-30Hr

Sturdy ABS housing. LCD screen. ACT sync. 24MHz band.
Industry's only built-in volume control ensures remote volume adjustment of MIPRO MA-708 or MA-808 wireless PA system installed with MRM-70 or MRM-72 receiver module.
MORE


ACT-30T

Sturdy ABS housing. LCD screen.
Miniature, compact & lightweight design.
ACT sync. 24MHz band.
MORE

NEW ACT 7 Series

ACT-71

Single-Channel ● 1/2U Rack-Mountable Metal Receiver.
400 Selectable Frequencies ● 48 Preset Compatible Channels
True Diversity Reception ● 72MHz Wideband

MORE
NEW

ACT-72

Dual-Channel ● 1U Rack-Mountable Metal Receiver
400 Selectable Frequencies ● 48 Preset Compatible Channels
True Diversity Reception ● 72MHz Wideband
MORE
NEW

ACT-74

Quad-Channel ● 1U Rack-Mountable Metal Receiver
400 Selectable Frequencies ● 48 Preset Compatible Channels
True Diversity Reception ● 72MHz Wideband
MORE
NEW

ACT-70H

Rugged magnesium housing. LCD screen.
Interchangeable capsules. Gain settings.
ACT sync. 72MHz wideband.

MORE
NEW

ACT-70T

Rugged magnesium housing. LCD screen.
Smallest size. Gain settings.
ACT sync. 72MHz wideband.
MORE


ACT-717

Single-Channel. 1/2U rack-mountable metal receiver.
104 selectable frequencies. 16 preset compatible channels.
True Diversity Reception. 24MHz band.
MORE


ACT-727

Dual-Channel. 1U rack-mountable metal receiver.
104 selectable frequencies. 16 preset compatible channels.
True Diversity Reception. 24MHz band.
MORE


ACT-747

Quad-Channel. 1U rack-mountable metal receiver.
104 selectable frequencies. 16 preset compatible channels.
True Diversity Reception. 24MHz band.
MORE


ACT-7H

Rugged magnesium housing. LCD screen.
ACT sync. 24MHz band.
MORE


ACT-7T

Rugged magnesium housing. LCD screen.
ACT sync. 24MHz band.
MORE




Old Systems

RECEIVERS
Model
Description
ACT-707SE


UHF Single-Channel Diversity Receiver
  •  1/2-rack Frame
  • Auto scan & ACT-function
  • LED Display
  • 16 Preset Channels

Matching ACT-707HE handheld or ACT-707TE body pack transmitters.

ACT-707DE

UHF Duel-Channel Diversity Receiver

  • 1-rack Frame
  • Auto scan & ACT-function
  • LED Display
  • Dual 16 Preset Channels
Matching ACT-707HE handheld or ACT-707TE body pack transmitters.
ACT-707S



UHF Single-Channel Diversity Receiver

  • 1/2-rack Frame
  • Auto scan & ACT-function
  • Colour LCD Panel
  • 100 Preset Channels
Matching ACT-707H and ACT-707HM handheld or ACT-707T and ACT-707TM body pack transmitters.
ACT-707D
ACT-707D


UHF Duel-Channel Diversity Receiver

  • 1-rack Frame
  • Auto scan & ACT-function
  • Colour LCD Panel
  • Dual 100 Preset Channels

Matching ACT-707H and ACT-707HM handheld or ACT-707T and ACT-707TM body pack transmitters.

ACT-707
ACT-707


UHF 4-Channel Diversity Receiver

  • 4-Channel Frame
  • Auto scan & ACT-Function
  • Colour LCD Panel
  • PC-control of 64 channels

Matching ACT-707H and ACT-707HM handheld or ACT-707T and ACT-707TM body pack transmitters.

ACT-707M

ACT-707M


ACT-707M UHF Colour LCD Module

  • Colour LCD panel has bright and clear displays.
  • First in the market to introduce hot-swappable modular design allows quick and direct installation to ACT-707 mainframe and immediate use. Ensures easy operating, servicing, renew and upgrade flexibility.
  • Advance computer software. Includes full spectrum analysis and individual channel signal management and monitoring.
  • Access to nearly 1,000 frequencies, 9 pre-set groups in each 24MHz band.
  • Advanced design in spurious emission shielding; ultra high sensitivity; extreme low noise & spurious emission.

Back to the top
HANDHELD TRANSMITTERS
Model Description
ACT-707HE

ACT-707HE


Standard Handheld Transmitter

  • Plastic Housing
  • Power switch is located on the housing for easy operation.
  • LED panel displays power on/off and battery fuel gauge
  • Exclusive colour rear cap is available in 10 colours for channel identification.
  • Fine-crafted and ergonomically designed housing presents MIPRO's unique style.
  • The hypercardioid condenser microphone capsule is ideal for vocal, providing high fidelity, wide frequency response, high dynamic range, rapid transient response, low echo feedback, clarity and accuracy sound image contributes the best sound quality in the digital audio age.
  • Patented modularized capsule design provides extremely low handling-noise feature that other brands cannot compete.
  • Unique dual steel microphone head-grille design eliminates pop & wind noises and prevents worsening of high pitch loss and directionality.
  • Interchangeable microphone capsules are avaliable. A condenser or dynamic capsule to suit personal preference.
  • World's first ACT (Automatic Channel Targeting) function provides rapid and automatic channel setting of the transmitter.
  • High fidelity modulation circuitry is capable of accepting high input level and less distortion.
  • Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
  • Professional quality ensures no impact-damage.
ACT-707H

ACT-707H


Premium Handheld Transmitter

  • World's first ACT-technology. Once you press the [ACT] key on the receiver panel, the transmitter channel is rapidly and automatically locked to the receiver.
  • Maximum 148db SPL is achieved by the proprietary "Photo-cell Coupling" high dynamic range modulation circuitry.
  • Advanced efficient transmitting and low power consumption circuitry design with 2 AA batteries provides long operating hours.
  • LCD panel displays group, channel, error code and battery meter status simultaneously.
  • Integrated antenna, fine-crafted and ergonomically-designed housing.
  • Extremely low handling-noise feature leads the competitors.
  • Detachable upper microphone grille designs for easy after sales services and replacement.
  • Unique dual steel microphone head-grille design for anti-pop noise, suffers no impact damage when dropped.
  • The supercardioid vocal capsule with high fidelity, wide frequency response, high dynamic range, and transient response contributes the best sound quality in the digital audio age.
ACT-707HM

ACT-707HM


Professional Handheld Transmitter

Innovative Features
Professional audio engineers have their own microphone sound preferences via knowledge and experience and will not select simply based on name brands only. MIPRO handheld transmitters are fast becoming acceptance among the leading sound engineers, audio professionals and artists worldwide due to its innovative features, performance, reliability and cutting-edge technology not found on others.

MIPRO seeks Reproduction of the Natural Sound
Reproduction of the natural sound is MIPRO's design principle. ACT-707HM handheld transmitter features a hyper-cardioid directionality condenser capsule whose high fidelity, dynamic range, fast transient responses, low feedback howling and accurate sound image characteristics personify as such.

High SPL Inputs Without Distortion
The ACT-707HM unique high fidelity modulation circuit can sustain a maximum SPL of 142 dB over the full input frequency range of 50 Hz ~ 15 KHz (+1 ~ -3 dB) while the THD is still under 0.9% linear width.

Furthermore, since the sensitivity of the modulation circuitry is preset to accurately match the sensitivity of the capsule, users are no longer required to adjust the sensitivity level of their wireless microphone to obtain the optimal output level and dynamic range. This technology gives a clear and powerful performance in the high frequency range without having to reduce the volume to avoid distortion, unlike many other manufacturer's designs.

Innovative ACT Function Replaces Traditional Manual Adjustment
ACT-707HM utilizes the UHF band and is PLL synthesized. A conventional PLL transmitter's frequency is set up manually. This can be complicated as well as prone to errors. In order to avoid these problems, MIPRO has designed and introduced the patented ACT function to replace conventional manual adjustments. These user-friendly systems work with just one press of the receiver's SCAN button to automatically, rapidly, and accurately set and lock the receiver's working frequency. This quick and accurate set-up avoids the mistakes so often seen in manually adjusted systems.

High-Efficiency Circuitry And Sophisticated PCB Design
Inside the ACT-707HM, there is a high-efficiency, low-spurious emission, low-power-consumption circuit which gives you a truly impressive 18 hours of operation using just 2 AA batteries. Expertise in wireless design and many years of wireless know-how can be easily seen in the precise circuit layout of the ACT-707HM.

Finely Crafted and Professionally Styled Housing
The professional look and feel of the patented ACT-707HM is worth noticing. MIPRO's principles of aesthetics and ergonomics combined with use of the best materials are fruition of these two handheld transmitter microphones.

Back to the top
BODY PACK TRANSMITTERS
Model Description
ACT-707TE




Standard Body Pack Transmitter

  • Plastic Housing
  • LED indicator displays power on/off and battery status
  • Compact, lightweight and streamline shape for easy wearing.
  • Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
  • Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
  • Belt clip allows 360 degrees rotating to suit transmitter wearing.
  • World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
  • Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
  • Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
ACT-707T

ACT-707T


Premium Body Pack Transmitter

  • Plastic Housing
  • LCD panel displays group, channel, error code, and battery fuel gauge simultaneously.
  • Compact, lightweight and streamline shape for easy wearing.
  • Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
  • Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
  • Belt clip allows 360 degrees rotating to suit transmitter wearing.
  • World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
  • Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
  • Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
  • Professional quality ensures no impact-damage.
ACT-707T

ACT-707T


Professional Body Pack Transmitter

  • Magnesium alloy housing.
  • LCD panel displays group, channel, error code, and battery fuel gauge simultaneously.
  • Compact, lightweight and streamline shape for easy wearing.
  • Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
  • Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
  • Belt clip allows 360 degrees rotating to suit transmitter wearing.
  • World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
  • Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
  • Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
  • Professional quality ensures no impact-damage.

Back to the top
LAVALIER MICROPHONES
Model Description
MU-53S

MU-53S


Premium Uni-directional Lavalier Microphone

Miniature 10mmφ. High gain before feedback. Warm, clear sound

  • Capsule Module(mm)10mmΦ premium uni-directional miniature condenser microphone
  • Frequency Response50Hz~18KHz ± 3dB
  • Capsule Impedance200Ω
  • Sensitivity -46dBV ± 3dBV/Pa (0dB=1V/Pa)
  • Maximum SPL142dB (Typical, 1%THD)
  • Capsule-shaft holder Dual - left and right side.
  • Plug MIPRO's mini XLR 4 pin plug or TA4F
  • Cable Length150 cm
  • Colour Black or Beige colour
  • Weights(g) 20
MU-55L / MU-55LS

MU-55L      MU-55LS


Omni-directional Lavalier Microphone

Sub-miniature 4.5mmφ. Low visibility.

Extended Frequency Response

  • Capsule Module(mm)10mmΦ premium uni-directional miniature condenser microphone
  • Frequency Response40Hz~20KHz ± 3dB
  • Capsule Impedance200Ω
  • Sensitivity -49dBV±3dBV/Pa(0dB=1V/Pa)
  • Maximum SPL125dB (Typical, 1%THD)
  • Capsule-shaft holder Dual - left and right side.
  • Plug MIPRO's mini XLR 4 pin plug or TA4F
  • Cable Length150 cm
  • Colour Black or Beige colour
  • Weights(g) 15

Back to the top
HEADWORN MICROPHONES
Model Description
MU-53HN

MU-53HN


All Purpose Headworn Microphone

Premium Miniature Microphone

  • Uni-directional pick-up pattern
  • Visually unobtrusive and comfortable to wear.
  • Flexible and durable frame with comfortable, soft ear hooks which require no adjustment for optimum comfort
  • Interchangeable MU-53M uni-directional capsule module and MU-55M subminiature waterproof omni-directional capsule module.
  • Featuring a high dynamic range and able to withstand a maximum SPL without distortion.
  • Capsule module and cable are easily detached from the frame and can be worn on the left or right side of the frame to suit personal preferences.
  • The very thin capsule-shaft mount is fully rotatable.
  • The capsule-shaft allows for adjustments in length, direction and angle for precise and optimum capsule positioning in relation to the speakers mouth.
  • Patented, swivelling earhook design allows for inward rotation, facilitating easy storage, packaging and carriage.
  • Available in black and beige colours.
  • Flexible gooseneck.
  • Supplied as standard with MIPRO's mini XLR plug.
  • Features a smooth, warm, natural sound.
MU-55HN / MU-55NHS

MU-55HN


All Purpose Headworn Microphone


Subminiture, Sweatproof, Microphone

  • Designed for demanding live performance.
  • Omni-directional pick-up pattern.
  • Visually unobtrusive and comfortable to wear.
  • Flexible and durable frame with comfortable, soft ear hooks which require no adjustment for optimum comfort
  • Interchangeable MU-53M uni-directional capsule module and MU-55M subminiature waterproof omni-directional capsule module.
  • Featuring a high dynamic range and able to withstand a maximum SPL without distortion.
  • Capsule module and cable are easily detached from the frame and can be worn on the left or right side of the frame to suit personal preferences.
  • The very thin capsule-shaft mount is fully rotatable.
  • The capsule-shaft allows for adjustments in length, direction and angle for precise and optimum capsule positioning in relation to the speakers mouth.
  • Patented, swivelling earhook design allows for inward rotation, facilitating easy storage, packaging and carriage.
  • Available in black and beige colours.
  • Flexible gooseneck.
  • Supplied as standard with MIPRO's mini XLR plug.
  • Features a smooth, warm, natural sound.

Back to the top
Optional Headset Microphones

Countryman E6 Isomax EarSets
Omni-Directional Microphones


E6
Light Beige - Flat Respose
Perfect on stage or in church, Isomax EarSets are the answer when you need the highest possible sound quality without the bulk and appearance of conventional headsets. Light and springy, Isomax EarSets clip around your ear, not around your head. They never interfere with your hairstyle, headphones or hat. Isomax EarSets are available in four colors, Light Beige, Tan, Cocoa, and Black to blend with the user's appearance. The E6 is supplied with your choice of cables that attach to the EarSet with a snap-on connector. Choose the 1 mm diameter cable for minimum visibility or our exclusive DuraMax 2 mm cable for unmatched life. A wide variety of connectors can be attached at the factory making Isomax EarSets instantly compatible with any mix board or wireless microphone transmitter

Features:
  • Unobtrusive
  • Isomax EarSets are by far the smallest, lightest and least visible headworn microphones.
  • Conveniently Designed
  • Wide Frequency Response
  • Omnidirectional pick up pattern Clips directly to your ear. No conflict with hairstyles. No adjustment needed for the width of your head. The cable attaches with a quick connect connector for easy service.
  • The E6 has the wide 50Hz to 20kHz response of a world class vocal microphone.
  • Reduces Feedback
  • Versatile
  • Available for use with most wireless transmitters.
  • Hard wired phantom power operation with adapter.
  • Handles High Sound Levels
  • Up to 145dB SPL
Moisture Resistant:
  • Resistant to the sweat and moisture on stage
General Specifications:
  • Frequency Response:50Hz to 20kHz
  • Operating Voltage:1 - 3.0 Volts
  • Current Drain:320uA nominal
  • Colours Available: Black, Light Beige, Cocoa.
Click here to download a
                                  printable PDF file Click here to download a printable PDF file

Rode HS-1 B and HS-1 P Headset Microphone



Whether you're presenting for television or live on-stage; in a 20,000 seat auditorium or in a house of worship, RØDE has all your audio requirements covered with the reliable and intuitive HS1 headset.



Featuring the pure, clear audio and low handling noise that RØDE is celebrated for, the HS1 is built to deliver and to last.



Subtle, ergonomic design including three axes of mechanical adjustment, a malleable, ultra lightweight tube arm and headband, and the choice of either black (HS1-B) or pink (HS1-P) models ensure the perfect fit and function for each individual.



Knowing that versatility is paramount in any product, RØDE has developed the MiConTM connector system which provides seamless integration between all of RØDE's compact wearable microphones and a wide range of wireless systems.



Visit the MiConTM product page for a full list of available adaptors and the supported devices.



RØDE has always offered industry leading warranty and after sales service on its products, and the HS1 is no exception, offering an innovative five year warranty that gives you total piece of mind for five years after purchase.



Specifications:



Power

Min 2V - Max 5V through MiCon wireless adaptors P48 through MiCon XLR adaptor

Acoustic Principle

Permanently polarised condenser

Directional Pattern

Omni-directional

Frequency range

60Hz - 18kHz

Output impedance

3kΩ Typical

Signal noise ratio

69dB

Equivalent noise

25dBA SPL (per IEC651)

Maximum SPL

110dB (clipping SPL)

Maximum output voltage

189mV (Calc. from max SPL peak before clip)

Sensitivity

-33.5dB re 1 V/Pa (1.6mV @ 94dB SPL) ± 3dB @ 1kHz

Weight

6.5gm

Dimensions

65mmH x 140mmW x 200mmD






Click here to download a
                                        printable PDF file Click here to download a printable PDF file

Redback Skin Tone Headband Presenters Microphone - C8912



C8912
                                      Head Band MicrophoneA feather light, comfortable headband style microphone designed for presenters, entertainers, marriage celebrants etc. The two ear hook design ensures minimal movement and maximum comfort. The boom is extendible and can be fitted to either side to suit individual requirements. Skin coloured finish. Fitted with a 3 pin mini XLR connector.


Specifications

Polar Pattern:
Omni-directional
Frequency Response:
20-20kHz
Impedance:
1,100 Ohms ± 30% (at 1K Hz)
Sensitivity:
65 dB ± 3dB (0dB=1V/ microbar)
Max Input Sound Level:
125 dB SPL, 1 kHz at 1% T.H.D.
Operating Voltage:
1V-10V DC
Capsule Housing:
4 x 11mm
Boom:
150mm
Cable Length:
1m
Connection:
3 Pin Mini XLR


Click here to download a
                                    printable PDF file Click here to download a printable PDF file

Redback Lecture Light Weight Microphone
Skintone – C8914


Redback Lecture Light Weight
                                    Microphone Skintone – C8914A lightweight buff coloured omni-directional electret microphone designed for presenters, entertainers etc. Designed to sit around your ear comfortably even when used for long periods. Fits either left or right ear and the boom can be adjusted to suit individuals requirements. For optimal performance the microphone capsule should be located on the jaw line of the user below the mouth. A small clip is provided to secure cable to the user’s collar for unhindered head movement. Fitted with 3 pin mini XLR and 1.2m lead.

Note: A wind sock is provided for outside use only & should not be necessary if microphone is located correctly.

Specifications:

Type: Back Electret Condenser
Impedance: 1500Ω balanced
Frequency response: 50Hz - 18kHz
Sensitivity: -60dB ±3dB

Spare Parts:

C0348 Spare windsock to suit
C0348 Spare Wind Sock

Click here to download a
                                  printable PDF file Click here to download a printable PDF file


Click Here to Download Focus On News Letter
Aiphone intercoms Nexia, Audia, Media Matrix DSP systems.
AKG, Beyer Dynamic, Rode, Sennheiser, Shure,
microphones and headphones
Mipro radio microphones (Catalogue)
Altronics and Jaycar electronics Mitsubishi
                Projectors(Multimedia Displays)
Australian Monitor, Biema, Crown, Lab Gruppen, QSC, Redback, Yamaha amplifiers Epson Video Projectors  Epson Video Projectors
Bose, EV, KV2, JBL, Tannoy, Turbosound speakers LG, Samsung Display Screens.
AMX and Crestron control systems Panasonic, Sansung CCTV
Denon Hi-Fi TOA TOA megaphones and PA (Catalogue)
Hills and Matchmaster TV antennas Niles architectural audio
Roland, Soundcraft, Mackie, A & H audio mixers. Multitone DECT phones










We also provide a prompt and efficient 24-hour technical service department for any situation that may arise.

Please contact us to arrange an obligation free quotation or consultation.

Hoping to be of service to you in the future.




This site is best viewed at 1280 x 1024 pixels

© 2007 Total Electronic Contracting
